Product overview(If used with OCS-3RL sensor, please note)

Product performance description

It can convert TTL signal to RS-485 digital output and 4-20mA analog output using Modbus protocol (The function needs to be customized),which need to be used with ultrasonic sensor of winpower technology

Specification

Size and Connectors

Wiring method with sensor

Special note 1: The digital output ports of all sensors in our company are J2, which can be connected with the 485 module of our company. The following picture shows the connection mode of one sensor J2 and 485 adapter board, as well as other sensors connected with 485.

Special note 2: The terminal connecting to the sensor of the 485 module cannot connect to the 12V power input (the sensor terminal of the 485 module cannot be powered by the display board of our company).

As shown below: front and back of the line

Protocol specification

◆1.RS485 MODBUS-RTU

​◆2.Default address: 0x16 ​

◆3.Default communication settings: 9600,n,8,1

With the OCS-3RL sensor

Communication instance

With the OCS-3RL sensor
